3. Car audio electronics
  5. Epicenter In-Dash

Epicenter In-Dash

Epicenter In-Dash

Technical Highlights

  • Input impedance 10kΩ, output impedance 160Ω, 13.5Vrms max.
  • Frequency response from 10Hz-100kHz, total distortion 0.003%.
  • Voltage display, 70dB-SPL to 160dB-SPL, current consumption 285mA.
  • More technical details
€349.00
€349.00 €349.00
2% discount with credit card

Your price match offer

ProductEpicenter In-Dash

Reply within 1–3 working days · Mon–Fri. Outside the EU, we are happy to review an individual offer.

Privacy

This website is protected by hCaptcha. The privacy policy and terms of service of hCaptcha apply.
including VAT
Pre-order now · Dispatch when stock arrives Pre-order · Ships when restocked
This product is currently out of stock at the supplier. As soon as it becomes available again, it will be dispatched to you automatically. We cannot provide an exact delivery date yet.
x piece
  • American Express
  • Apple Pay
  • Bancontact
  • BLIK
  • EPS
  • Google Pay
  • iDEAL Wero
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Shop Pay
  • Twint
  • Union Pay
  • Visa

Delivery & availability

Pre-order: this variant is not currently in our stock. Without a confirmed delivery date we cannot give an exact arrival date. We ship once the goods are available.

Orders ship together based on the item with the longest lead time. If you need something sooner, ask by email about a possible partial shipment beforehand.

Shipping costs and options depend on the destination. Check the shipping calculator; final costs are shown before placing the order.

Email us the product, car, existing system and budget. We will offer an alternative available sooner.

Ask for an alternative available sooner

Reply in 1–3 working days · Mon–Fri

1 year extra warranty

Every product purchased from Masori includes an additional year of warranty in the third year after purchase (months 25–36). We cover repair or replacement free of charge for covered warranty claims. Automatic and free – exclusively for Masori customers. Your statutory rights remain unaffected.

Warranty terms
datasheet
Audio SystemDSP 8.12
Audio System-DSP 8.12-12-Kanal DSP-masori-kaufen
Audiocontrol-LC6i-High-Low Adapter-masori-kaufen
AudiocontrolLC6i
Audiocontrol-Epicenter In-Dash-SPL-Messgerät-masori-kaufen
€349.00
€349.00 €349.00

Discover the Epicenter In-Dash, a high-low adapter from the brand Audiocontrol. This device brings the deepest bass of your car radio system to life and also offers live SPL measurement up to 160 dB. With the unique Para-Bass equalizer, you have the ability to tune the bass playback to your vehicle, achieving the best sound experience. In addition to bass enhancement, the Epicenter In-Dash also allows you to monitor the voltage of your vehicle's electrical system. This high-low adapter combines advanced technology with user-friendliness, providing an unparalleled sound experience.


features

  • AudioControls unique circuit for bass restoration
  • SPL display up to 160 dB
  • Battery voltage display
  • Speaker level inputs
  • Para-BASS controller
  • Symmetric Difference Inputs

ENTRANCES

  • Preamplifier inputs: 1 (2 channels)
  • Maximum input level: 15Vrms
  • Speaker level inputs: 1 (2 channels)
  • Input impedance: 10kΩ

EXITS

  • Preamp outputs: 1 (2 channels)
  • Maximum output level: 13.5 Vrms
  • Output impedance: 160Ω

PERFORMANCE

  • Harmonic Total Distortion: 0.003%
  • Frequency response: 10Hz-100kHz
  • Signal-to-noise ratio: 110dB
  • Symmetrical input noise suppression: 60dB
  • Microphone SPL range: 70 dB-SPL to 160 dB-SPL

CONTROL

  • remote control input

GENERAL

  • Power Supply: High Headroom PWM Switching
  • Current consumption: 285mA
  • Recommended security value: 1A

WEIGHT & DIMENSIONS

  • Dimensions: 17.1cm x 13 x 2.5cm
  • Weight: 0.9kg

Immediately available SPL Meter

    datasheet

    Open data sheet

    Frequently Asked Questions about Epicenter In-Dash

    What does the Para-BASS controller do in the Audiocontrol Epicenter In-Dash?

    The Para-BASS controller of the Audiocontrol Epicenter In-Dash allows you to precisely adjust the bass playback to achieve an optimal sound experience. This feature enhances the low frequencies and ensures that each audio session can be individually tailored. By adjusting the Para-BASS controller, you can vary the bass intensity as needed. This is particularly beneficial when listening to various music genres, as each type of music often requires a different bass emphasis. The controller works in conjunction with AudioControl's unique circuitry, designed to ensure powerful bass playback, even when the original recording has a weak bass presence.

    What is the maximum input level of the Epicenter In-Dash?

    The maximum input level of the Audiocontrol Epicenter In-Dash is 15Vrms. This means that the device can process input signals with a maximum peak voltage of up to 15 volts without distortion. Such a level is remarkable for a car radio system and shows that the Epicenter In-Dash is capable of working with powerful source components. You can easily use the high-low adapter with various factory systems and aftermarket amplifiers, as the high input threshold ensures that there is no clipping or signal distortion during more intense use.

    What information does the SPL display of the Epicenter In-Dash provide?

    The SPL display of the Audiocontrol Epicenter In-Dash gives you the ability to monitor the sound pressure level in your vehicle, with a measurement range from 70 dB-SPL to an impressive 160 dB-SPL. With this display, you can see at any time how loud your system is playing, which can be useful for tuning and sound optimizations. The SPL display helps you identify and maintain the optimal sound level, especially when participating in car audio events or competitions. It is a useful tool to maximize the performance of your audio system while staying within safe volume limits.

    How does the Epicenter In-Dash process audio signals from speakers?

    The Audiocontrol Epicenter In-Dash features speaker level inputs with a maximum input impedance of 10kΩ. This function ensures that audio signals can be directly captured from your vehicle's speakers, facilitating compatibility with a variety of audio systems. The balanced differential inputs help minimize interference by canceling out noise that may occur in unshielded speaker cables. This allows you to feed high-quality audio signals into your system, regardless of the original audio source, while ensuring clean and clear sound reproduction without distortion or loss of sound quality.

    What are the dimensions of the Audiocontrol Epicenter In-Dash?

    The dimensions of the Audiocontrol Epicenter In-Dash are 17.1 cm x 13 cm x 2.5 cm. This compact size allows for flexible installation in various vehicle types without taking up much space. When installing, it is important to consider the dimensions of your specific vehicle to ensure ideal placement. Accurate measurement of the available space or consulting the vehicle manual is strongly recommended to ensure that the device can be mounted in the desired position. The compact measurements allow for discreet integration into your vehicle's dashboard or glove compartment.

    How is the voltage in the vehicle monitored by the Epicenter In-Dash?

    The Audiocontrol Epicenter In-Dash features a built-in battery voltage display that allows you to keep an eye on your vehicle's electrical supply. This function is particularly useful for early detection of potential electrical issues and responding accordingly. By continuously monitoring, you can ensure that your audio system always receives optimal supply voltage and avoid power outages or voltage drops that could affect audio playback. This helps maintain system health and ensures consistent performance under various operating conditions, whether stationary or while driving.

    How does total harmonic distortion affect the sound quality of the Epicenter In-Dash?

    The total harmonic distortion (THD) of the Audiocontrol Epicenter In-Dash is extremely low at 0.003%. This low distortion is crucial for maintaining sound integrity, as it ensures that the audio signal is reproduced without unwanted interference or distortion. A low THD guarantees clear and precise sound, which is of utmost importance for audiophiles and music lovers. By minimizing distortion, the Epicenter In-Dash provides flawless audio playback and allows you to immerse yourself deeply in soundscapes without losing details in the audio image.

    What channels does the Epicenter In-Dash support for inputs and outputs?

    The Audiocontrol Epicenter In-Dash supports 2 channels for both inputs and outputs. This means that both preamp and speaker level inputs are designed for stereo signals, allowing you to create a balanced sound image for left and right. The preamp outputs deliver an equivalent stereo signal to subsequent amplifiers or audio systems, preserving the integrity of the stereo sound. This 2-channel design is ideal for most modern car radio systems capable of driving both front and rear speakers simultaneously.

    What is the signal-to-noise ratio of the Epicenter In-Dash?

    The signal-to-noise ratio of the Audiocontrol Epicenter In-Dash is 110 dB, indicating excellent noise suppression. A high signal-to-noise ratio is essential for minimizing interference in the audio signal and achieving clean sound reproduction without audible noise. This allows you to experience clear and uncolored playback even during quiet passages in the music. Music lovers can hear the finest details in their favorite tracks without the audio image being marred by background noise. High noise suppression is particularly important when the sound level is increased to enhance the experience in the car.

    What advantages do the balanced differential inputs of the Epicenter In-Dash offer?

    The balanced differential inputs of the Audiocontrol Epicenter In-Dash are specifically designed to minimize interference and noise in the audio signal. They promote efficient signal processing by eliminating disturbances that may occur on the input lines. Practically, this means that even in a noisy electrical environment, as often found in vehicles, the quality of the audio signal remains clear and accurate. These inputs are particularly useful in situations where cables are run far across the vehicle, as they balance out the interference signal and pave the way for unparalleled sound, regardless of potential external interferences.
